Specification |
 |
|
 |
Model |
CPD.03.30ET
|
|
Optical |
Color corrected infinity optical system |
●
|
|
Head |
Trinocular head, 30°inclined, Interpupillary Distance 54-75mm 360 degreerotatable eyepiece tube 360 |
●
|
|
Eyepiece |
PL10x/20mm, Wide Field, High Eye Point, Diopter Adjustable +/-5 Degree |
●
|
|
Objective |
OIP infinity plan achromatic objective 4X/0.06 WD=7.18mm |
●
|
| OIP infinity plan achromatic objective 10X/0.25 WD=4.70mm |
●
|
| OIP infinity plan achromatic objective 40X/0.65 WD=0.72mm |
●
|
| OIP infinity plan achromatic objective 100X /1.25 WD=0.15mm |
●
|
|
Nosepiece |
Backward Quadruple |
●
|
|
Condenser |
Kohler N.A. 1.25, with Socket for Phase Contrast and Dark Field Slides, Center Fixed |
●
|
|
Illumination |
100V~240V fluctuate of voltage. 3W high brightness LED , adjustable brightness, Center Fixed |
|
|
Stage |
150x140mm mechanical stage with damping clips, moving range: 76x50mm |
●
|
| Focusing
|
Coaxial focus system with tension adjustment, with up-limited. Moving range: 30mm |
●
|
| Packing Info |
Carton demension 58x56x28cm (Chargealbe weight about 18kgs by express carrier ), Gross weight 12kgs |
●
|
|
|
|
|
|
|
Optional Accessory |
|
|
 |
| |
|
Order No. |
| Eyepiece |
PL10x/22mm, Wide Field, High Eye Point, Diopter Adjustable +/-5 Degree for CPD.03.30E
|
EYE.03.PL10/22 |
| Objective |
Infinity Plan Achromatic 20x/0.40 |
OBJ.03.E30-IPL20 |
| Nosepiece |
Backward Quintuple |
|
| Filter |
Blue, Dia.45 |
|
| Yellow,Dia.45 |
|
| Green, Dia.45 |
|
| Netural, Dia.45 |
|
| Adapter |
C-Mount 1.0x, Focus Adjustable |
|
| C-Mount 0.5x, Focus Adjustable , for 1/2 CCD |
|
| C-Mount 0.35x, Focus Adjustable, for 1/3 CCD |
|
| Photo Adapter with PK or MD mount, with 3.2x Photo Eyepiece |
|
| Dark Field Slider |
Dark Field Slider for 4x~40x Objective |
FCA.03. E30-DF |
| Polarizing Kit |
Polarizer |
FCA.03. E30-PL |
| Analyser |
FCA.03. E30-AL |
| Phase Contrast Accessory |
Centering Telescope, Dia.30mm |
PHA.03.TEL-30 |
| Phase Contrast Slide, for 10x, 40x Infinity Objective |
PHA..03.SL10/40 |
| Phase Contrast Slide, for 20x,100x Infinity Objective |
PHA..03.SL10/100 |
| N.A.1.25 Kohler Illumination Turnplate Phase Contrast Condense Set, For 10x,20x,40x,100x Phase Contrast Observation |
PHA..03.N125-BF |
| N.A.1.25 Kohler Illumination Turnplate Phase Contrast Condenser with Dark Field Set for 10x,40x,100x Phase Contrast Observation and Dark Filed Observation |
PHA..03.N125-DF |
| Infinity Plan Phase Contrast Objective 10x/0.25, W.D.=4.70mm (For BF or DF) |
OBJ.03.PH10IPL |
| Infinity Plan Phase Contrast Objective 20x/0.50, W.D.=1.75mm (For BF) |
OBJ.03.PH20IPL |
| Infinity Plan Phase Contrast Objective 40x/0.65, W.D.=0.72mm (For BF or DF) |
OBJ.03.PH40IPL |
| Infinity Plan Phase Contrast Objective 100x/1.25, W.D.=0.15mm (For BF) |
OBJ.03.PH100IPL |
| Bright Field Turnplate Phase Contrast Kit |
This Kit Includes:
--N.A.1.25 Kohler Illumination Turnplate Phase Contrast Condense Set, For 10x,20x,40x,100x Phase Contrast Observation
--Infinity Plan Phase Contrast Objective 10x/0.25, W.D.=4.70mm
--Infinity Plan Phase Contrast Objective 20x/0.50, W.D.=1.75mm
--Infinity Plan Phase Contrast Objective 40x/0.65, W.D.=0.72mm
--Infinity Plan Phase Contrast Objective 100x/1.25, W.D.=0.15mm
--Centering Telescope, Dia.30mm |
PHA.03.TIPL-BF |
| Dark Field Turnplate Phase Contrast Kit |
This Kit Includes:
--N.A.1.25 Kohler Illumination Turnplate Phase Contrast Condenser with Dark Field Hole for 10x,40x,100x Phase Contrast Observation and Dark Filed Observation
--Infinity Plan Phase Contrast Objective 10x/0.25, W.D.=4.70mm
--Infinity Plan Phase Contrast Objective 40x/0.65, W.D.=0.72mm
--Infinity Plan Phase Contrast Objective 100x/1.25, W.D.=0.15mm
--Centering Telescope, Dia.30mm |
PHA.03.TIPL-DF |
|
|
|
|
|
Research Level Microscope
