CPR.22.100 Forensic Comparison Microscope
|
| Magnification |
3.8x~230x |
| Head |
Bionocular Head, 30° Incline, Interpupilary Distance 48~75mm, Diopter +/-5 Adjustable
,with VIDEO port and PHOTO port |
| Eyepiece |
WF10x/22mm, High Eyepoint |
| WF20x/12mm, High Eyepoint |
| Objective |
5 Step Zoom Plan Objective 0.8x, 1.25x, 2x, 3.2x, 4.8x |
| Auxiliary Lens 0.4x, 2.0x |
| Working Distance |
101mm |
| View Field |
Dia. 2.3~62mm |
| Magnification Correcting |
Magnification Correction System, with Correcting Lens |
| Separation Line Adjusting |
Seperation Line Adjust System in Back, with Special Designed Adjust Driver |
| Working Stage |
Square Manual Working Stage 90*90mm, Moving Range 54*54*54mm |
| Round Titable Working Stage Dia. 90mm, 0-45° Inclined, 360° Rotatable |
| Joint Left/Right Moving Range 54mm, Joint Up/Down Range 60mm |
| Bullet Holder |
Bullet Holder Set for all kinds of Bullet, Cartridge and other Objects |
| Light Source |
12V50W Fan Cooling Strong Halogen Light, Brightness Adjustable (Pair) |
| 5W LED Cold Light, High Brightness, Brightness Adjustable (Pair) |
| Coaxial Light Lens for observing in deep hole, or smooth object surface (Pair) |
| Polarizing Light Lens, for eliminating flare lights and dazzling lights; (Pair) |
| Transmit Bottom Light |
| Filters: Red,Green, UV |
| Adapter |
Built-in 0.5x CCD Adapter |
Front View Photo Adapter for SLR Digital Camera
For user to view and take photo easily |
| Power |
80~240V Wide Range Voltage |
| Dimension |
Instrument Size 37*30*63cm |
Research Level Microscope
