| Item |
Specification |
LCD.06.E620-4KM20 |
| Optical System |
NIS60 Infinity Optical System |
● |
| Eyepiece |
EW10x/22mm |
● |
| 4K Digital HDMI PAD Camera |
4K Digital HDMI PAD Camera |
● |
| Viewing Head |
Infinity, Seidentopf Trinocular Viewing Head, Inclined at 30°，
Interpupillary 47-78mm, splitting ratio 50/50 (100/0 or 0/100 is optional) |
● |
| Objective |
NIS60 Infinity Plan Objective 4X |
● |
| NIS60 Infinity Plan Objective 10X |
● |
| NIS60 Infinity Plan Objective 40X |
● |
| NIS60 Infinity Plan Objective 100X,Oil |
● |
| NIS60 Infinity Plan Objective 100X Water |
○ |
| NIS60 Infinity Phase Contrast Objective PH10X |
○ |
| NIS60 Infinity Phase Contrast Objective PH20X |
○ |
| NIS60 Infinity Phase Contrast Objective PH40X |
○ |
| NIS60 Infinity Phase Contrast Objective PH100X |
○ |
| Nosepiece |
Coded Backward Quintuple Nosepiece |
● |
| Rackless Stage |
Rackless Stage 230mm x 150mm, Moving Range 78mm x 54mm, Anti-scratch surface |
● |
| Condenser |
Sliding Abbe Condenser NA1.25(Including Empty Plate) |
● |
| Bright Field 10x- 40x Phase Contrast Slider |
○ |
| Bright Field 100x Phase Contrast Slider |
○ |
| Dark Field Slider |
○ |
| Focusing System |
Coaxial Coarse and Fine Adjustment, Coarse Stroke 37.7mm
per Rotation, Fine Stroke 0.2mm per Rotation, Fine division
0.002mm,Moving Range 30mm |
● |
| Illumination |
3W S-LED (LCD Display Magnification, Timing Sleep, Brightness Indication and Lock, etc.) |
● |
Fluorescence
attachment |
3W LED, Two Wave Range (B, G, U, V can be combined), Fly-eye Lens Illumination |
○ |
| Accessories |
1x CCD adapter |
○ |
| 0.5x CCD adapter |
● |
| Simple Polarization Set |
○ |
| Filter |
Green |
● |
Research Level Microscope
