LGT.43.LM600 High Performance LED Light Engine for Leica/Nikon/Olympus/Zeiss
Description and Notes
LGT.43.LM600 LED Light engine
LED Light engine with excellent performance, adopts the latest generation of UHPLED technology, which offers intense broad-spectrum illumination for imaging most common fluorescent stains. The price is the best value on the market, delivering higher performance than other traditional HBO fluorescence illuminator systems and other LED products of the same grade
Recommended Applications
•Normal fluorescence
• Immunofluorescence
• DNA Analysis
• Live Cell Imaging
• Whole Slide Imaging
• Near-Infrared DIC
• Histology and Cytology
• Calcium/Ion Imaging
• Forensic Analysis
• Semiconductor Inspection
• Metallurgical Microscopy
• Gel Documentation
Specification
BULB TYPE Light-emitting diode
BULB LIFETIME 50,000Hours(attenuation to70%, 25,000Hrs)
Light source frequency 100MHz
HIGH SPEED CAMERA Max 16,000FPS(exp>60μs)
channel switch Motor-driven
CONTROLLER Keypad w/ LCD
INPUT DC 24V
Switching Power ADAPTER AC 100-240V 50Hz
DYE SUPPORTED DAPI, CFP, Aqua, FITC, TRITC, TxRed, Cy5
Alexa Fluor 350,405,430,488,514
Alexa Fluor 532,546,555,568,594
Alexa Fluor 610,633,647,660,680,700,750
R-G-B Sequence cycle Not available
External trigger Optional
Pulse stroboflash Not available
ELECTRONIC SHUTTER Optional
SUPPORTED microscope Nikon, Olympus, Leica, Zeiss
Operating Environment 0~30℃, <60% RH (No condensation)
